Seedbed cultivators of the STURMVOGEL model produced by RABE (Germany)
Designed for pre-sowing tillage after plowing. Uniform cutting, good mixing, the possibility of continuous overlap and high-quality undercutting. Vertically folding sections. Mounted machines. Double row packers and leveling plates are standard for better and even soil distribution. Various choice of working bodies allows you to optimally equip the machine for different types of soil.
Basic equipment:
- All models mounted
- Category III hitch
- Hydraulic folding in sections
- Transport width 3 m
- Leveling knife with spring protection and planning knife for models 7500 L and 9000 L
- Chopper roller Ø 440 for 4501 LS/ 6001 LS
- Double rear roller Ø 330+Ø 270 mm for 7500 and 9000 L
STURMVOGEL |
4501LS |
6001LS |
7500L |
9000L |
Working width, m |
4.5 |
6,0 |
7.5 |
9,0 |
Transport width, m |
3,0 |
3,0 |
3,0 |
3,0 |
Tractor power, l s |
180 |
230 |
260 |
300 |
Weight without rollers, kg |
2293 |
2666 |
2945 |
3440 |
Cast-iron roller crumbler |
yes |
yes |
||
Plate rollers |
yes |
yes |
