Ricosma Atilla Evo trailed sprayers

Trailed sprayers Atilla Evo series manufactured by Ricosma, Italy

Basic equipment:

Type:
Trailed sprayer for application by spraying aqueous solutions of herbicides, fungicides.

Bar:
Composite, hydraulically folded, collision protection, mechanical compensation, reinforced. Zinc coated for protection. Autonomous hydraulic control system. Boom lifting height — 1.5 m.

Pneumatic boom stabilization system for working on uneven ground.

Control boom hydraulic system directly from the motion computer. 5 nozzle sections on the boom.

Mounting nozzles with the simultaneous installation of three different nozzles (3 sets of nozzles included).

Frame:
All-metal, coated with a layer of zinc for protection.

Capacity:
Plastic one-piece, washing tank — 200 l, hand washing tank — 20 l, mixer for mixing concentrates — 30 l. Graduated liquid level scale.

Working fluid supply system:
Diaphragm type pump with electric flow control system, solution preparation system for liquid and bulk concentrates, tank injection system, multi-stage filtration system. Pump productivity — 250 l / min. Water pump alarm.

Electronic control system for the supply of working fluid — BRAVO, the computer is installed in the tractor cab (monitoring the flow rate, changing parameters on the move, counting areas).

Wheels:
Standard size 230/95R44

Road lighting

Rigid hitch — hitch diameter 50mm

Drive shaft (PTO)

Sprayer models:

Note:
Sprayers can be equipped with various navigation systems (parallel driving, field map, etc.)
